Adjustable Log Cross-cut Saw

1.Adjustable cutting length and feed speed for various log sizes.
2.Fully automatic: feeding, aligning, cross-cutting in one run.
3.Precise dimensions, smooth ends, less wood waste.
4.Pneumatic one-button control, one operator.

Share：

Contact us Inquiry

Detailed Description

Detailed Description

Product Parameters
Equipment Model DMJ-YD-2000D DMJ-YD-3000D
Total machine weight 3800 kg 4200 kg
Overall dimensions 3200 × 3700 × 2200 mm 4250 × 3700 × 2200 mm
Maximum Sawing Diameter 320 mm 320 mm
Maximum sawing length 2200 mm 3200 mm
Applicable wood materials Various types of round logs such as eucalyptus wood, pine wood, miscellaneous wood and poplar wood Various types of round logs such as eucalyptus wood, pine wood, miscellaneous wood and poplar wood
Conveyor chain assembly 4 groups 4 groups
Saw blade specifications Ø900 × 6 mm Ø900 × 6 mm
Cutting Length 600 - 1000 mm 900 - 1500 mm
Feed speed 2 – 10 m/min (Variable-frequency adjustable) 2 – 10 m/min (Variable-frequency adjustable)
Sawing Motor 11 kW - 4-pole × 3 pcs 11 kW - 4-pole × 3 pcs
Feeding Motor 2.2 kW - 4-pole 2.2 kW - 4-pole
Edge motor 2.2 kW - 4-pole 2.2 kW - 4-pole
Supporting Expansion It can be matched with a conveying feeding rack and discharging rack to form an assembly line. It can be matched with a conveying feeding rack and discharging rack to form an assembly line.
